Frinso Radar Level Sensor
Continuous. Contactless. Reliable.
Industrial-grade radar for liquids, slurries, and solids. Built-in IoT, real-time analytics, and SCADA integration for 24/7 accuracy — even in harsh conditions.
Precision Through Innovation
24 / 80 GHz FMCW radar for precise, maintenance-free operation.
Liquids, slurries, chemicals, and even solids with dust or vapor.
Stream data to Frinso Cloud and SCADA/EMS for real-time control.
Adaptive echo filtering stabilizes readings under foam or dust.
Easy installation and calibration via local or remote interface.
Rugged build for humidity, dust, and high-temperature sites.
Radar Precision You Can Trust
High-frequency microwave pulses reflect off the material surface. The time delay between emission and echo is converted to level using advanced FMCW processing for extreme accuracy.
With built-in IoT, level data is sent instantly to the Frinso Cloud or SCADA for visualization, alarms, and reports.
“Real-time, non-intrusive, and maintenance-free — even under extreme process conditions.”
Smart. Connected. Real-Time.
- 📊 Live level, volume & trend visualization
- ⚙️ SCADA integration for centralized monitoring
- 🔔 Alerts for abnormal levels and overflows
- ☁️ Cloud data storage & analytics
- 🔄 Over-the-air (OTA) updates & config
Technical Specifications
| Measuring Range | Up to 30 m (liquid) / 70 m (solid) |
| Frequency | 24 GHz / 80 GHz FMCW Radar |
| Accuracy | ±2 mm |
| Beam Angle | ≈ 6° (typical) |
| Output | 4–20 mA / RS-485 / Modbus / LoRa / GSM |
| Power Supply | 18–28 V DC / Solar Compatible |
| Material | PTFE / SS316 / PP |
| Protection Class | IP68 (Ex-proof optional) |
| Operating Temperature | -40°C to +120°C |
| Display | OLED or Remote LCD (optional) |
| Integration | SCADA / EMS / Frinso IoT Cloud / API |
Universal Across Industries
Accurate level for liquids and powders in manufacturing.
Continuous tank/sump monitoring with IoT dashboards.
Safe, non-contact sensing in corrosive/hazardous areas.
Real-time reservoir levels with SCADA integration.
Smart Dashboard — Visualize What You Measure
- • Real-time level data with trend analysis
- • Historical reports & export options
- • Multi-location monitoring
- • Alert configuration & status logs
- • SCADA / Modbus RTU / MQTT compatible
Installation & Configuration
- • Mount on tanks, silos, or reservoirs.
- • No contact with liquid/solid surface required.
- • Configure via display keys or remote interface.
- • Compatible with solar and wired power systems.
- • Minimal maintenance with IP68 protection.
Sustainability & Innovation
Reduce waste, prevent overflows, and enhance process efficiency — with intelligent radar monitoring that supports your sustainability goals.
“Frinso Radar Level Sensor — Precision Beyond Sight. Intelligence Beyond Limits.”
Measure Smarter. Operate Safer. Monitor Anywhere.
From Field Measurement to Cloud Intelligence — The Frinso Advantage.
