Frinso Smart Piezometer
Accurate Subsurface Pressure & Groundwater Level Monitoring.
Designed for groundwater wells, dams, and hydrological projects. Equipped with IoT telemetry and Frinso Cloud analytics for real-time insights.
Smart Monitoring. Deep Insights.
Measures pore-water pressure and groundwater levels with sub-centimeter accuracy.
Real-time data via GSM, GPRS, or LoRa to Frinso Cloud or SCADA systems.
Battery or solar-powered variants for long-term remote deployments.
Records pressure, depth, and temperature trends continuously.
Rugged stainless-steel body designed for harsh environmental conditions.
Easy installation with Frinso FlowLinc Gateway or standalone IoT unit.
Pressure to Intelligence
The Smart Piezometer measures hydrostatic pressure exerted by the water column above it. This pressure is converted into electrical signals and transmitted via IoT or SCADA systems.
Users can remotely track groundwater levels, pore pressure trends, and hydraulic gradients in real-time — enabling predictive water management.
Transforming field pressure data into actionable intelligence.
IoT & SCADA Integration — Data at Your Fingertips
Integrated seamlessly with Frinso IoT and SCADA ecosystems, the Smart Piezometer enables live data visualization, analytics, and automated alerts for efficient water infrastructure monitoring.
Technical Specifications
| Measurement Type | Pore Pressure / Water Level |
| Sensor Type | Vented / Non-Vented Pressure Transducer |
| Range | 0–100 m (Customizable) |
| Accuracy | ±0.25% F.S. |
| Output | 4–20 mA / RS-485 / LoRa / GSM |
| Power Supply | 9–28V DC / Solar with Battery |
| Ingress Protection | IP68 |
| Material | Stainless Steel / PVC Housing |
| Cable Length | As per site requirement |
| Operating Temp. | -10°C to +70°C |
| Integration | SCADA, EMS, Frinso IoT Cloud, API Compatible |
Applications Across Sectors
Continuous aquifer level observation.
Pore pressure tracking in dams, tunnels, and bridges.
Subsurface seepage and water intrusion control.
Long-term hydrogeological and recharge analysis.
Smart Data Visualization
- • Real-time pressure and level trends
- • Multi-site data analytics
- • Historical trend exports
- • Remote calibration & alerts
- • AI-based anomaly detection
Installation & Maintenance
- • Simple drop-in sensor with vented cable.
- • OTA calibration and updates via Frinso Cloud.
- • Minimal maintenance, long-term stability.
- • Compatible with borewells, dams, and reservoirs.
Sustainability & Innovation
Combining IoT, renewable power, and data analytics — Frinso Smart Piezometer enables sustainable groundwater management through intelligent monitoring.
“Empowering Smart, Sustainable Groundwater Monitoring Across India.”
Measure Deeper. Think Smarter. Manage Better.
Frinso Smart Piezometer — Turning Groundwater Pressure into Cloud-Based Intelligence.
