Frinso Bulk Flowmeter – Mechanical Water Meter
Accurate. Durable. Smart Integration Ready.
Mechanical Precision Meets Digital Intelligence — enabling robust, accurate, and IoT-ready volumetric measurement for utilities and industries.
Product Overview
Proven multi-jet / Woltman technology ensures accuracy & longevity.
Seamlessly integrates with IoT, AMR, or SCADA systems.
Supports DN15 to DN200 and higher diameters for bulk flow.
Integrates easily with existing telemetry or AMR networks.
Designed for continuous operation with minimal power draw.
Corrosion-resistant construction with IP68 protection.
Technical Specifications
| Model | LXSY15–40 / LXLY50–200 |
| Accuracy Class | Class B (ISO 4064 Certified) |
| Flow Range | Up to 800 m³/h |
| Operating Pressure | 1.6 MPa |
| Pressure Loss | ≤ 0.63 MPa |
| Medium | Cold / Hot Water |
| Temperature Range | 0.1°C – 90°C |
| Body Material | Cast Iron |
| Output Signal | Pulse / RS-485 / M-Bus (AMR Ready) |
| Power Supply | 9–24V DC |
| Display | Mechanical Counter (m³) |
| Protection | IP68 (optional) |
| Mounting | Horizontal or Vertical Installation |
AMR & IoT Connectivity
📶 Pulse Output for remote data collection.
☁️ RS-485 MODBUS integration with Frinso AI dashboards.
🔔 M-Bus protocol for Automatic Meter Reading (AMR).
🌐 Compatible with Frinso FlowLinc™ LoRa / NB-IoT gateways.
⚙️ Custom baud rate (1200–9600 bps) & voltage configuration.
📊 Instant data from mechanical meters to cloud analytics.
AI & Dashboard Integration
AI-powered flow anomaly detection.
Algorithm-based alerts from pulse data.
Hourly & DMA-level consumption tracking.
Flow deviation & fault-based alerts.
Applications
Bulk metering at inlets, ESRs & DMAs.
Consumption monitoring & billing systems.
Process water measurement in plants.
Flow metering in canals and lift irrigation.
Reliable IoT-enabled water tracking.
SCADA-based consumption mapping.
Thermal/cooling flow verification.
Centralized AMR-based monitoring.
Design & Installation
🧩 Compact Inline Design – horizontal or vertical mount options.
⚙️ Clear Mechanical Dial – displays totalized flow in m³.
🧰 Magnetic Coupling – ensures leak-proof measurement transfer.
🔋 Pulse Sensor – waterproof housing with easy access.
💧 Maintenance-Free – no lubrication required.
Durability & Protection
🛡️ Cast iron body with anti-corrosion coating.
🌊 IP68-rated electronics for outdoor & chamber use.
💪 Heat resistant up to 90°C (hot water models).
⚙️ Designed for fluctuating pressures & 24x7 operation.
Project Deployments
💧 Mission Bhagiratha – DMA bulk flow monitoring
🏭 Industrial WTPs – Pulse-based flow integration into SCADA
🌾 Lift Irrigation Projects – Flow tracking for distribution
🏙️ Smart Water Supply Systems – Frinso AI-based visualization
Why Choose Frinso Bulk Flowmeter
Rugged Mechanical Design for long service life
Pulse / RS-485 Output – AMR & IoT ready
Class B Accuracy as per ISO 4064
Compatible with Frinso Real-Time Dashboard
Ideal for Water Boards, Industries & Utilities
Connect Legacy Measurement to Smart Infrastructure
Upgrade your mechanical water meters with Frinso IoT and AI dashboards for seamless, data-driven operations.
