Frinso Battery-Based Electromagnetic Flowmeter (EMF)
Smart. Self-Powered. Always Connected.
The next-generation instrument for accurate flow measurement where power is scarce. With internal lithium battery and IoT-ready telemetry, it keeps remote assets visible and compliant.
Product Overview
Frinso’s Battery-Operated EMF combines precision magnetic sensing with low-power digital electronics to deliver long-term flow measurement without external power or wiring.
Internal lithium battery powers continuous metering in off-grid sites.
Stable electromagnetic sensing even at low velocities.
Real-time data to Frinso Cloud via GSM/GPRS/Lora/RS-485.
IP68 submersible sensor + converter for chambers & pits.
No moving parts; magnetic keypad configuration without opening.
Technical Specifications
| Measuring Range | 0.3 – 10 m/s |
| Pipe Diameter | DN15 to DN600 |
| Accuracy | ±0.5% of reading |
| Power Supply | Internal Lithium Battery (5–10 years life) |
| Signal Output | RS-485 / MODBUS / GSM / GPRS / (LoRaWAN opt.) |
| Display | Local LCD / Remote Option |
| Process Connection | Flange (ASA 150 / PN10 / PN16) |
| Electrode Material | SS316 |
| Liner Material | PTFE / Rubber |
| Ingress Protection | IP68 (Submersible Type) |
| Operating Temp. | 0°C to 60°C |
| Data Storage | Internal logger with daily flow totalization |
IoT & Cloud Connectivity
Reliable data anytime, anywhere — even from off-grid installations.
Flow, totals, battery, and system health in real time.
Dashboards, trends, and reports for fleets of meters.
Low battery, reverse flow, zero flow, leakage detection.
RS-485 / MODBUS RTU / GSM / GPRS / LoRaWAN.
Reliable store-and-forward with onboard logging.
AI-Based Flow Intelligence
Detect anomalies, leakages, and tampering patterns.
Consumption patterns for DMA/zone planning.
Adaptive sampling extends life dynamically.
Pre-emptive alerts before sensor degradation.
Integration Example: EMF + Pressure + AI Dashboard = Complete Smart Water Utility Solution.
Key Applications
OHTs, ESRs & DMA zone metering.
Canals, distributaries and lift systems.
Process consumption analytics.
CGWA compliance with flow + level.
Effluent reporting under CPCB norms.
Distributed assets with AMI.
Temporary site water metering.
Plug-and-measure deployments.
Installation & Display
Compact unit with local LCD and battery indicator.
5–10 m display cable for chamber installs.
Easy retrofitting with standard connections.
Configure without opening the enclosure.
Durability & Protection
Submersible-ready for pits and flooded chambers.
Secure housing and mounts for field reliability.
Stable under electrical noise and vibration.
Designed for harsh outdoor environments.
Project Use Cases
Why Choose Frinso Battery EMF
True Off-Grid Operation with IoT intelligence
High Accuracy, maintenance-free design
Modular Connectivity: GSM / LoRa / Modbus
Rugged IP68 housing for outdoor reliability
AI-powered dashboard with predictive insights
Powerless Doesn’t Mean Connectionless.
Explore the battery-powered EMF with real-time IoT connectivity and AI analytics for dependable off-grid water intelligence.
